กล้อง FPV Camera CAM 700TVL lens 2.1mm fpv racing drone โดรนซิ่ง โดรนเกษตร

Product Name: 700 Line Shell Size: 25mm * 25mm, Weight: 9.5g Total pixels: PAL: 1020H 596V (610000 images) NTSC: 1020H 508V (520000 images) Effective pixels: PAL: 976H 582V VW) NTSC: 976H 494V (480,000 images) Signal format: PAL / NTSC (default PAL format, NTSC selectable) Resolution (horizontal center): 700TVL Video output amplitude: 1.0Vp-p / 75 Automatic gain control: 0.25 / 0.50 / 0.75 / 1.00 four levels can be adjusted, it can be up to 55dB White balance: On / off selectable exposure modes: electronic exposure electronic shutter: 1/50 (1/60) - 1/100000 second gamma Ma correction: 0.45 / 1.0 Synchronous method: Internal synchronization Lens: Standard 2.8mm lens Operating voltage: DC5-12V (wide voltage, the measured can work properly 5-13V) Operating current: 70mA (low power consumption) Operating temperature: -20 ℃ - 60 ℃ Humidity: 0% ~ 98%
