Dimensions (L x W x H)
140 x 150 x 86mm
Cybenetics Rating
GOLD
80 Plus Rating
GOLD
ATX Version
Intel ATX 12V v3.1
Protections
OVP / OPP / SCP / OCP / UVP / OTP / NLO / SIP
Certification
CB / CE / FCC / TUV / cTUVus / BSMI / CCC NOM / FCC IC / UKCA / TUV / TUV S-Mark / cTUVus
PFC
0.99
Input Voltage
100-240V
Input Current
850W: 12A
750W: 10A
650W: 10A
Input Frequency
47Hz-63Hz
DC Output Voltage
+5V | +3.3V | +12V | -12V | +5Vsb
Total Output
850W: +5V/+3.3V :22A, +12V:70.8A, -12V:0.3A, +5Vsb:3A
750W: +5V/+3.3V :22A, +12V:62.5A, -12V:0.3A, +5Vsb:3A
650W: +5V/+3.3V :20A, +12V:54.1A, -12V:0.3A, +5Vsb:3A
Power Excursion
850W: 1997W (*up to 235% of the PSU's rated power for 100μs)
750W: 1762W (*up to 235% of the PSU's rated power for 100μs)
650W: 1527W(*up to 235% of the PSU's rated power for 100μs)
Operating Temperature
40°C
Fan Size
120mm FDB Fan
Fan Bearing
FDB (Fluid Dynamic Bearing)
Fan Speed
2400 RPM
MTBF
100K hours at full load
ATX 24 Pin Connector
1
EPS 8 Pin Connector
2
PCI-E 6+2 Pin Connector
850W / 750W: 3
650W: 2
Molex 4 Pin Connector
2
12V-2x6 (12+4) Connector (600W)
850W / 750W: 1
12V-2x6 (12+4) Connector (450W)
650W: 1
SATA Connector
6
Weight
850W / 750W:
Product + Cables: 1450g+1350g
with Package: 3.03kg
650W:
Product + Cables: 1450g+1320g
with Package: 3kg
Warranty
7 years
