Cf ไดรเวอร์สเต็ปมอเตอร์ดิจิทัล Dm556 2 เฟส 5.6A คุณภาพสูง สําหรับสเต็ปมอเตอร์ 57 86

DM556 Digital Stepper Motor Driver 2-Phase 5.6A Controller for Nema 23 57mm 34 86mm Stepping Motor Replaces M556 Specification: Input power: 24 to 50V DC power supply, the capacity is not less than 200VA, the typical value is DC 36V Output current: 1.0A to 4.2A, 8 levels adjustable, 0.5A resolution Drive mode: dual-machine constant current PWM drive output Insulation resistance: > 500MΩ under normal temperature and pressure Insulation strength: 500V/min at normal temperature and pressure Cooling method: natural cooling Use occasion: avoid dust, oil mist and corrosive gas Use temperature: 0℃ to +50℃ Environmental humidity: <80%RH, no condensation, no frost Product size: 115*76*34mm/4.53*2.99*1.34" Note: 1. There may be slight size deviations due to manual measurement, different measuring methods and tools. 2. The picture may not reflect the actual color of the item because of different photographing light, angle and display monitor. Included: 1 X Stepper Motor Driver
