แผงวงจร12 V To 220 V Pure Sine Wave Inverter 500 W ตัวควบคุมแรงดันไฟฟ้า

NEW 1PC inverter 12v to 220V pure sine wave inverter Driver board 500W with voltage regulator The input voltage: 10 v to 15 v Output waveform: square wave, sine wave (according to the use of transformer and 220 v voltage feedback decision, no feedback square wave) Quasi sine wave inverter driven plate Need external 50 hz, 220 v transformer 8-12 v transformer, even greater than 10 v above the feedback voltage 220 v, also may not be able to voltage stability, low pressure side of a winding can (standard transformer silicon steel sheet) Power transformer is suitable for 800 w, the largest output power 500 w Small transformer can't be output power, such as 50 w transformer cannot output power 80 w Voltage stabilizing function: when the transformer is close to 12 v, no voltage stabilizing function, the output pulse, voltage stabilizing function for 8 v to 10 v transformer is, there are fine for the customer to adjust the voltage, voltage stabilizing function to meet the 220 v to 220 v voltage sampling board Have input reverse connect protection function With 10 v low voltage under-voltage protection function Output frequency: 50 hz, could be "tuned" (before shipment has been adjusted to 50 hz) Output voltage, adjusted to about the 220 v before shipment, this kind of ac side voltage regulator has fluctuated With a small fan when can in transformer output capacitance with fixed waveform, can output approximately sine wave, but a capacitive will consume a certain amount of power, reduce the conversion efficiency, do not bring the perceptual load, plus a capacitor is not recommended
